1、 UPS power capacityRated capacity: 100KVA, 120KVA, 160KVA, 200KVA, 250KVA, 300KVA, 400KVA, 500KVA, 600KVAActive power: 90kW, 108kW, 144kW, 180kW, 225kW, 270kW, 360kW, 450kW, 540kW

2、 UPS power supply main circuitInput method: three-phase+ground wireRated AC

input: 380/400/415VAC

Voltage range: 285VAC-498VAC

Rated frequency: 50/60Hz

Frequency range: 45-66Hz

Input power slow start delay: 5-600s can be set

Rectifier soft start: 6-100s can be set

3、 UPS power bypass output

Rated AC input: 380/400/415AC (three-phase+neutral)

Voltage range: -40% -+20% can be setFrequency range: 50/60Hz± 10% (± 2.5%,± 5%,± 10%,± 20% can be set)

Rated AC output: 380/400/415VACVoltage stabilization accuracy:± 1% (100% balanced load),± 2% (100% unbalanced load)

Power factor: 0.9Voltage dynamic transient5% (0-100% load variation)Total harmonic voltage distortion:<1% (100% linear load),<3% (100% nonlinear load)

Voltage dynamic response time: ＜ 5msFrequency synchronization tracking range:&plusmn; 2Hz (&plusmn; 0.5-&plusmn; 3Hz can be set)

Inverter overload capacity: 105% long-term operation, 110% 1 hour, 125% 10 minutes, 150% 1 minute

Frequency accuracy:&plusmn; 0.05%

Waveform: Pure sine wave

4、 UPS power efficiencyNormal mode: 94%ECO mode: 98%

5、 UPS power supply usage environmentTemperature: 0-40 ℃Humidity: 0-95% without condensationNoise (1m):&le; 67dB

6、 UPS power control managementRS232, RS485: Supports Windows XP/7/8/Linux/MacOptional SNMP card: supports remote monitoring and management through a network browser managed by SNMP
