1、 UPS power capacityRated capacity: 10KVA, 15KVA, 20KVA, 30KVA, 40KVA, 60KVA, 80KVAActive power: 9kW, 13.5kW, 18kW, 27kW, 36kW, 54kW, 72kW

2、 UPS power supply main circuitInput method: three-phase+ground wireRated AC input: 380/400/415VACVoltage range: 285VAC-498VACRated frequency: 50/60HzFrequency range: 45-66HzInput power slow start delay: 5-600s can be setRectifier soft start: 6-100s can be set

3、 UPS power bypass outputRated AC input: 380/400/415AC (three-phase+neutral)Voltage range: -40%&plusmn; 20% can be setFrequency range: 50/60Hz&plusmn; 10% (&plusmn; 2.5%,&plusmn; 5%,&plusmn; 10%,&plusmn; 20% can be set)Rated AC output: 380/400/415VACVoltage stabilization accuracy:&plusmn; 1% (100% balanced load),&plusmn; 2% (100% unbalanced load)Power factor: 0.9Voltage dynamic transient:&plusmn; 5% (0-100% load variation)Total harmonic voltage distortion:<1% (100% linear load),<3% (100% nonlinear load)Voltage dynamic response time: ＜ 5msFrequency synchronization tracking range:&plusmn; 2Hz (&plusmn; 0.5-&plusmn; 3Hz can be set)Inverter overload capacity: 105% long-term operation, 110% 1 hour, 125% 10 minutes, 150% 1 minuteFrequency accuracy:&plusmn; 0.05%Waveform: Pure sine wave

4、 ProtectionProtection level: IP30 (IP31 or above can be achieved through optional components)Surge protection: Meet IEC60664-1, withstand 1.2/50uS+8/20uS, above 6KV/3KA (meet D-level lightning protection requirements)

5、 UPS power efficiencyNormal mode: 92%ECO mode: 98%

6、 UPS power supply usage environmentTemperature: 0-40 ℃Humidity: 0-95% without condensation

7、 UPS power control managementRS232, RS485: Supports Windows XP/7/8/Linux/MacOptional SNMP card: supports remote monitoring and management through a network browser managed by SNMP

8、 Compliant with standardsSafety regulations: IEC60950-1, IEC62040-1-1Electromagnetic compatibility: IEC62040-2, IEC62040-3Note: Special requirements can be customized, and product parameters are subject to no further notice.Yantai Haibo Electrical Equipment Co., Ltd. focuses on customized research and development, production, sales, and technical services for large capacity lithium-ion battery packs, intelligent AC/DC power supply sets, building automation equipment, and computer monitoring systems. We are committed to providing overall technical and product solutions for new energy applications, green intelligent buildings, and energy conservation and emission reduction. Our main products are aimed at industries such as high-rise buildings, power substations, power plants, petrochemicals, metallurgy, and rail transit. Contact number: 0535-8209058
